Plastic Water Pipe Locator

SKU: TS2954DXmic
$6,200.00Price

Locate plastic water lines. The Radiodetection Electronic transonde coupled with the FCS DXMic uses acoustic to locate distances over 500ft and can also be used to locate leaks.

Locate underground plastic water pipes easily by using sound.  This electronic transonde is used to vibrate the water as it passes through it sending a minute sound wave back along the pipe. This sound wave is then detected using the DXMic receiver giving a location of the water pipe.



The DXmic also doubles as a top leak detector.  It has the latest generation ground microphone and features from FCS.


  • Auto filtering
  • Frequency display
  • Audio recordings in the DXmic Pro version
  • The DXmic App* provides for download and transfer of site details and recordings (Pro)
  • GPS location (Pro version using the DXMic app)


The device is supplied in a robust carry case which can also be used as a charging station for the system


Key Features and Benefit

  • Excellent audio: Best in class sound quality
  • Durable: Robust housing with carry strap fixings
  • Colour touch screen: Clear multifunctional graphics and ease of use
  • Wireless capability: For headphones or transfer of audio/configuration data to PC (Wireless or standard headphone options )
  • Frequency display: For each analysis and filter setting
  • Flexible: Auto and manual filters Clear upgrade path: Compatible with Xmic foot and handprobe sensor
  • Clear upgrade path: Compatible with Xmic foot and handprobe sensor
  • USB capability: For data transfer and firmware updates
  • Long battery life: Li-ion cells with up to 15-25 hrs Battery life
  • User friendly: Safety Noise Level cut off and leak noise isolation filters
  • Improved automatic filtering: Supported by frequency analysis display (Pro)
  • App version*: For download of results and remote transfer (Pro)
  • Minimum level noise recording and display: For effective pinpointing


DXmic App* (Pro version)

  • Android or IOS version
  • Uses GPS to give location
  • Upload photos from site and add site notes
  • DXmic downloads its own reference to add to operator reference
  • DXmic Pro downloads sound files to the App
  • Everything can be emailed to the office from site, saving travel and providing immediate detailed, remote reports
  • After download benefit from transfer and printing facilities for reports



Features
Frequency range 0 to 5000Hz
Battery life Minimum 25 hours (with battery saving) 15 hours (constant)
Battery charge Maximum 8 hours
Charger Universal 110-240V AC mains charger with 12V DC output (Optional in car adapter) all items can be charged in case .USB socket for lead phone charging
Weight 600g (with batteries)
Temperature Operating temperature range -15C to +50C
Dimensions 193H x 109W x 60D mm (7.5”H x 4.2”W x 2.3”D)
Keypad Touch screen LCD
Display 5.0 inch TFT LCD color
Ingress protection  IP65
Headphone connection Wireless or cable connection. With safety noise cut off
Headphones Bluetooth linked or Studio quality headphones are supplied as standard Aviation quality headphones are available as an option
Rmic ground microphone High sensitivity piezo-electric sensor mounted in windproof, nitrile rubber housing. Low noise 1.5m cable Weight: 2.9kg
Hand probe Attachment optional The hand probe is supplied with a tripod foot and two aluminium probe rods for sounding in soft ground plus magnetic contact for better coupling to fittings each probe rod is 400mm in length
Displays  - Filter selection with noise level indicator and frequency analysis
- Minimum level profiling
- Device settings
DXmic Pro version

Includes:
- Recording of leak noise
- Replay of leak noise and download to App
- Increased memory capacity to maximize recordings
